Harlequin 5000FS Fuel Station Bunded Diesel Tank
From £2,995.00 ex VAT
From £3,519.13 inc VAT
|
 |
| Product Information |
 |
|
| Product Reference: |
5000FS |
| Maximum Capacity: |
5307 litres |
| Nominal Capacity: |
5042 litres |
| Length: |
2950 mm |
| Width: |
2520 mm |
| Height: |
2500 mm |
| Material: |
MDPE Plastic |
| UV Stabilised: |
Yes |
|
Related Products
Important Product Information
Please note that due to exceptional demand this product is currently subject to a 6 week delivery leadtime.
Product Overview
Harlequin Bunded Fuel Station Tanks are the complete diesel storage solution. Incorporating a space-saving vertical design, integral bunding and supplied with a host of value added features as standard, they are ideal for installation at agricultural, commercial, industrial and institutional premises… in fact anywhere there is a requirement to store and to dispense diesel fuel!
Standard Equipment: All Models
Rotationally moulded bunded diesel storage and dispensing tank, supplied complete with:
-
2” BSP Offset Lockable Fill Point
-
Fill Pipe with Non Return Valve and Isolation Valve
-
2” Vent
-
Piusi Ocio Electronic Oil Tank Contents Gauge with +/-1% accuracy
-
Harlequin Electronic Bund Warning Alarm
-
LRC Failsafe Overfill Prevention Probe
-
Lockable Door and Manhole Access
-
30 micron Particulate and Water Filter
-
6 metre Fuel Delivery Hose
-
Three stage Automatic Shut Off Nozzle
-
Emergency Isolation Switch
-
Bunded Construction
-
High Accuracy Digital Flow Meter with +/0.5% accuracy [+/-0.2% repeatability]
Additional Standard Equipment: 240v Only
-
Bulkhead Light
-
240v Power Supply
- 72 litres per minute Electric Pump
Additional Standard Equipment: 110v Only
-
110v Power Supply
- 56 litres per minute Electric Pump
Additional Standard Equipment: 12v and 24v Only
-
12v or 24v Power Supply
-
Battery Fly Leads
- 56 litres per minute Electric Pump
5000FS-240FM Fuel Station with 80 User Fuel Management System
Specification as per Harlequin 5000FS-240 Fuel Station 240 volt but additionally supplied with factory fitted fuel management system complete with Secure Key activation. Restricts refuelling to users issued with a Secure Key, reducing the risk of unauthorised use, fuel theft and fraud. Suitable for use with up to 80 users and supplied as standard with:
The fuel management system automatically memorises the last 200 fills and this information can be hardwired to a PC up to 0.8km away, or downloaded and transferred via the Administration Key.
Please note that when a fuel management system is specified, a digital flow meter is not supplied.
All Harlequin Fuel Stations supplied with a Fuel Management System now come complete with free on site system commissioning - that's a saving of £350+VAT.
Applications
Plastic bunded storage and dispensing tank suitable for use with Diesel (D) and BioDiesel [with a bio element not exceeding 5% concentration] fuel at agricultural, commercial, industrial and institutional installations. For higher concentrations, please see Harlequin's 5000BFS BioFuel Station - suitable for use with BioDiesel blends of up to B100 [i.e. 100% bio-element concentration].
Fully compliant with all relevant product requirements contained within The Control of Pollution (Oil Storage) (England) Regulations 2001, The Water Environment (Oil Storage) (Scotland) Regulations 2006 and comparable requirements throughout the United Kingdom.
Installation Requirements
This tank must be installed by a suitably competent person in accordance with statutory requirements.
All mains electrical connections must only be undertaken by a qualified electrician in accordance with prevailing statutory requirements. It is recommended that all 240v Bunded Fuel Stations are connected to an RCD protected mains power supply.
Product Information
Additional product information can be obtained by downloading the Harlequin Range brochure - click the link below:
Delivery and Payment
Price(s) stated are inclusive of delivery to any address in Great Britain or Northern Ireland, excluding offshore locations and subject to access for an articulated lorry. If access to your premises is restricted please advise at time of order placement.
Please note it is the customer’s responsibility to arrange for the tank to be offloaded from the delivery vehicle to the customer’s premises. Please note that due to exceptional demand, this product is subject to an extended delivery period. Please allow up to 20 working days for delivery.
TankDepot.co.uk accepts Delta, Maestro / Switch, Mastercard and Visa. Your credit / debit card will be charged at time of order placement.
IMPORTANT INFORMATION Please note that all images are supplied for reference purposes only. All tank dimensions and capacities stated are approximate. Maximum capacity stated is equivalent to the brimful capacity of the tank. Nominal capacities stated are equivalent to 95% of actual tank capacity. Consistent with TankDepot.co.uk’s policy of continual improvement, the right is reserved to amend product specifications without notice. E&OE.
